Quantitative Filling and Evacuation based stations for assembly lines, service centers and rework bays.

Fluidyne’s Automotive oil dispensers are the standard of filling in automotive assembly lines which enable quality assurance, drip-free filling and compliance to cycle time.

Fluidyne automotive oil dispensers are engineered for high-performance fluid handling in automotive assembly and aftermarket service environments, aligning with following standards –

  1. TQM (Total Quality Management)
  2. IEC 60204-1 – Electrical safety
  3. ISO 12100 – Low Risk filling operations
  4. IEC 61000 – Electromagnetic compatibility

Core Information

Fluidyne’s Automotive oil dispensers are built in two main offerings –
Series 6700 – Liquid Filling Machines for oils, adblue, fuels
Series 6780 – Evac n Fill for brake, coolant, PAS and oil filling applications requiring evacuation technology

Transfer sub-system

  • Built-in storage tanks
  • Transfer pumps
  • Filters (100 um/25 um/3 um)

  • Gear pumps for oils. Centrifugal pumps for water-based media
  • Filling rate – 10/20/40/70 LPM

  • Oscillating piston positive displacement meter by Fluidyne
  • Resolution – 12 ml with DN20, 5 ml with DN15
  • Repeatability – Better than ±0.02%

  • Zero-drip variant for quantitative filling
  • Evac-Fill-Leveling nozzles
  • Specialized electric wire-free design for gasoline dispensing

  • PLC-HMI options per your requirement
  • VFD integration with pump
  • Barcode scanner and printer enabled
  • MES output via Profinet/OPC UA/Ethernet

Apart from these, the other major components of the 6780 are –

Evacuation System

  • Vane vacuum pumps
  • Vacuum traps for leveling cycles
  • 30 mbar for coolant, 1 mbar for brake, 2 mbar for PAS
  • Optional evacuation for tanks (Brake Oil)

  • Vacuum, pressure transmitters

The 6700 series is also available with channel stacking upto 9 channels with common control panel.

  • Multi-channel variants upto 9 channels

  • Mezzanine mounting with operator panel options
  • Precision dispensing with oscillating piston flow meters
  • Drip-tight nozzles
  • Designed for error-proofing (Poka-Yoke) and compliant with 5S and Kaizen initiatives

  • Supports CAPA (Corrective and Preventive Action) frameworks through historical dispensing data and fault trace logs

  • Interface-ready with MES/ERP systems for real-time traceability and OEE (Overall Equipment Effectiveness)tracking
  • Supports PFMEA and process validation protocols with built-in alarms for fill volume deviation and air entrapment
  • Achieve quality control via interlocking and alarm software

Why Choose Automotive Oil Dispensers?

  • Automotive oil dispensers ensure 100% TQM compliance
  • Safe filling without spillage risks
  • Reduced downtime

  • EMC certified

  • Incur savings on costly fluids due to precise dispensing
  • Direct automation connector options
  • Industry 4.0 enabled

Applications

Electric Vehicles

  • Transmission oil
  • Brake
  • Coolant – BCS and TCS

IC Engines

  • Gasoline
  • HSD
  • Brake Oil
  • Coolant
  • PAS
  • Clutch
  • Adblue
  • Windscreen washer fluid

Motorcycles

  • Brake
  • Coolant
  • Gasoline

Construction Equipment

  • Diesel
  • Adblue
  • Coolant
  • Brake
  • Axle Oil
  • Hydraulic Oil

Series 6780-B Brake Filling Machine

Series 6780-C Coolant Filling

FAQ’s

What is an automotive oil dispenser?

An automotive oil dispenser is a precision system used to store, meter, and accurately fill fluids such as engine oil, brake fluid, coolant, transmission oil, hydraulic oil, and fuels. Designed for OEM assembly lines and service workshops, these dispensers ensure contamination-free delivery, precise volumes, and operator safety. Configurable as engine oil dispensers, brake filling machines, coolant filling machines, or fuel filling machines, they support efficiency, compliance, and global quality standards.

Fluidyne automotive oil dispensers are designed for precision, safety, and contamination-free delivery of a wide range of fluids. They handle engine oils, transmission oils, brake fluids (DOT 3/4/5.1), coolants, hydraulic oils, fuels, and specialty lubricants. Configurable as engine oil dispensers, brake filling machines, coolant filling machines, or fuel filling machines, they ensure accurate filling for OEMs, service workshops, and off-highway equipment, while meeting global standards like TQM, CAPA, and EN ISO 12100.

Fluidyne offers advanced dispensing solutions for both workshop applications and automotive assembly lines.

  • The Series 6720 Retail Dispensing Units provide light commercial solutions for DEF, diesel, coolant, water, and low-viscous oils, featuring auto-shutoff nozzles, patented oscillating piston flow measurement, microcontroller-based electronics, integrated printer, and weights & measures certification.
  • The Series 6700 Automotive Line Filling Stations are assembly-line approved, with zero-drip nozzles, PLC-MMI electronics, inbuilt tanks up to 2 kL, and multiple pump options.
  • The Series 6780 Evac-n-Fill Stations handle brake, coolant, clutch, and power steering oils with vacuum-filling cycles, ECU integration, built-in pumps, and ±5 ml flow resolution.

Automotive oil dispensers today integrate seamlessly with MES and SCADA systems, enabling real-time monitoring, accurate flow measurement, and traceability across assembly lines and workshops.

By linking dispensing data with production orders, inventory, and quality records, these smart dispensers ensure efficiency, compliance, and cost control, transforming fluid management into a digital, data-driven process for modern automotive operations.

Automotive oil dispensers are available in both portable and fixed versions to suit different workshop and production needs. Portable dispensers, are trolley-mounted type available in 6720 series, allow flexibility across service bays.

Fixed dispensers are trolley mounted but are large in weight and dimensions and hence not meant for mobile applications. They are suited to high-volume dispensing in OEM assembly lines. Choosing between the two depends on workshop size, mobility needs, and dispensing capacity requirements.
