Batch Blending System

A batch blending system is where formulation discipline meets production reality. Whether blending solvents, specialty chemicals, additives, or finished products, accuracy at each batch step determines consistency, cost, and compliance. Fluidyne’s batch blending system, built on the proven 6730 Preset Batching System platform, is designed for industries that cannot afford approximation.

Unlike velocity-based systems that infer flow, a Fluidyne batch blending system measures actual volume transferred using oscillating piston positive displacement flowmeters. Every ingredient added to the blend is measured directly, repeatably, and independently of density, viscosity, or temperature variation. This makes the system ideal for chemical blending systems, repackaging systems, and controlled bulk transfers.

At its core, the batch blending system turns recipes into reality, one precise batch at a time.

Core Information

  • Core Architecture

    • Preset batch controller with multi-recipe capability
    • Oscillating piston positive displacement flowmeters on each ingredient line
    • Fast-acting on-off valves for sharp batch cut-off
    • Common blending header or blend tank interface
    • Local keypad or HMI-based operation

  • Blending Logic

    • Operator selects recipe and batch size
    • Preset batching system opens ingredient valves sequentially or simultaneously
    • Each flowmeter measures true volumetric input
    • Valves close precisely at preset batch volume
    • Final blend volume achieved without overrun

  • System Flexibility

    • Single-line or multi-line blending
    • Sequential or ratio-based batching
    • Skid-mounted or line-mounted configurations
    • Easy expansion for future ingredients
  • True volumetric batch blending system accuracy
  • High repeatability between batches
  • No dependency on density or viscosity
  • Excellent low-flow blending control
  • Minimal batch overrun
  • Reduced raw material giveaway
  • Consistent formulation quality
  • Faster batch cycles
  • Lower recalibration frequency
  • Reliable long-term performance
  • 6730 preset batching system platform
  • Oscillating piston PD flowmeters
  • Multi-recipe batch controller
  • Sharp on-off valve actuation
  • High batch resolution
  • Compact skid-based design
  • PLC and DCS integration ready
  • Low pressure loss
  • Compatible with aggressive chemicals
  • Minimal maintenance requirement

This configuration ensures the batch blending system remains accurate, repeatable, and easy to scale.

Applications

Chemical and
Solvent Blending

  • Solvent formulation blending
  • Acid and alkali blending
  • Chemical additive preparation
  • Intermediate product blending

Repackaging and
Trading

  • Bulk to drum repackaging systems
  • Finished product blending for resale
  • Batch-controlled tanker filling
  • Inventory-controlled dispatch

Pharmaceutical and
Specialty Chemicals

  • Controlled solvent charging
  • Formulation batching
  • High-value ingredient blending

Petrochemical
Industry

  • Blending of specialty fluids
  • Chemical injection batch preparation
  • Additive blending systems

FAQ’s

What is a batch blending system?

A batch blending system is a controlled setup used to combine multiple liquids in predefined volumes to create a consistent blend. Each ingredient is measured accurately before being added to the blend. This ensures repeatability, quality control, and cost efficiency, especially in chemical blending systems where formulation accuracy is critical.

Fluidyne’s batch blending system operates using a preset batching system and oscillating piston flowmeters. The operator selects a recipe and batch size, and the controller manages valve operation. Each ingredient is measured volumetrically and added until its preset quantity is reached, ensuring accurate and repeatable blending.

The key advantages include true volumetric measurement, high repeatability, and independence from fluid property variations. The system minimizes batch errors, reduces material giveaway, and delivers consistent blend quality. Its modular design also allows easy expansion and integration into existing production environments.

Fluidyne batch blending systems use oscillating piston positive displacement flowmeters. These flowmeters directly measure volume rather than inferring flow from velocity. This makes them ideal for batching and blending applications where accuracy, repeatability, and sharp cut-off at batch completion are essential.

Batch blending systems can be configured from semi-automatic to fully automatic operation. Automation options include recipe management, batch reporting, PLC or DCS communication, interlocks, and remote operation. This flexibility allows the system to match production scale, compliance needs, and operator skill levels.
